| 型号 | Model | JLD-380 |
|---|---|---|
| 锯切長度 | Max.Cutting lenght | 3800MM |
| 锯切厚度 | Max.Cutting thickness | 100- 120MM |
| 定位方式 | Positioning method | 自动Automatic |
| 定位精度 | Positioning accuracy | 士0.02mm |
| 锯切精度 | Cutting accuracy | 士0.10mm |
| 主锯電机功率 | Main saw motor power | 18.5kw*2 |
| 主锯轴外径 | Main saw blade diameter | 450mm |
| 主锯轴直径 | Main shaft diameter | 60mm |
| 主锯转速 | Main saw speed | 3800r/min |
| 锯車伺服電机功率 | Saw car servo motor power | 1.5kw |
| 机械手伺服電机 | Mechanical hand servo motor | 1. 5kw |
| 副锯電机功率 | Vice saw motor power | 2.2kw |
| 副锯片外径 | Vice saw blade diameter | 180mm |
| 副锯轴直径 | Sub shaft diameter | 30mm |
| 副锯转速 | Secondary saw speed | 5100r/min |
| 送料速度 | Feeding speed | 0~100M/min |
| 锯切速度 | Cutting speed | 0~120M/min |
| 回程速度 | Return speed | 0~150M/min |
| 空气压力 | Air pressure | 0.6-0.7MPA |
| 机床外形尺寸 | Machine tool dimension | 700mm X 12500mm |
| 净重 | Net weight | 约9200KG |
| 总功率 | Total power | 47kw |
